Description
MCPCBS-ALUMINIUM BACKED PCBS
Production Capacity :- 12000 sqm / month
Sector Catered : Automotive, Lighting, Industrial Electronics, Home Appliances, Railways, Power Electronics, Automation, Storage Devices, Solar Systems.
MCPCBS-ALUMINIUM BACKED PCBS (Copy)
| PRODUCTION CAPABILITY | |
| Type of Laminates | ACCL – 1W, 2W, 3W |
| Laminate Thickness | 0.8, 1.0, 1.2, 1.6 , 2.4, 3.2 (mm) |
| Copper Foil Thickness | Up to 140 microns |
| Maximum PCB Size | 1200 mm x 500 mm |
| Minimum Track Width | 0.10 mm ( 4 mil ) |
| Minimum Track Spacing | 0.10 mm ( 4 mil ) |
| Minimum Hole Diameter | 0.60 mm |
| Hole/ Outer Profile | CNC Drilling & CNC Routing, Punching & Blanking |
| Surface Finishing | ENIG, Lead Free HASL, HASL, OSP, LACQUER, Carbon Printed Contacts, Peelable Mask |
| Specifications. Standards | IPC-A-600, IPC-SM-840, IPC-RB-276, IPC-TM-650 |
| Reports | PDIR, Microsection, Solderability, FAI (First Article Inspection), PPAP Documents (On specific request) |
| System Approvals | IATF 16949:2016, ISO 9001:2015, ROHS Compliance |
